The Vogels black TVM 5405 Elite flat TV bracket is specially designed to fix your TV set as flat as possible against the wall. The TV bracket is suitable for screens from 32 to 77 inches and with a maximum weight of up to 75 kg. The bracket allows you to mount your TV at 1.5 cm from the wall. The Elite Fixed TV bracket has a built-in level to mount your device straight. There are also integrated cable clips to neatly hide the cables at the back. An installation manual, drilling template, screws and plugs are included to make installation a smooth process.

Important product information

Note! Also, always check the VESA size of your television to make sure this bracket fits.

Technical features
Product type	Wall bracket
Application	Televisions
Max. size compatibility (inch)	77 in
Min. size compatibility (inch)	32 in
Max. size compatibility (cm)	195 cm
Min. size compatibility (cm)	81 cm
Maximum load	75 kg
Agility	fix

Holder
Max. tilt angle	0 degrees
Max. pivot angle	0 degrees
Adjustable height	No
Distance to wall/ceiling	1.5 cm
Motor drive	No

Equipment
Cable tray	Yes
Remote control	No
Product certifications	TÜV

General features
VESA standard	100 mm x 100 mm, 100 mm x 200 mm, 200 mm x 100 mm, 200 mm x 200 mm, 200 mm x 300 mm, 300 mm x 200 mm, 300 mm x 300 mm, 400 mm x 200 mm, 400 mm x 300 mm,400 mm x 400 mm
Color (by manufacturer)	Black
Weight	1.8 kg
Scope of delivery	Wall mount
Manufacturer guarantee	15 Year
Manufacturer Part Number (MPN)	5854050

General Product Safety
GTIN8712285353086
Product typeWall bracket

Manufacturer
ManufacturerVogel's Products B.V.
Websitehttps://www.vogels.com
E-mail[email protected]
EU establishedYes
AddressHondsruglaan 93
CityEindhoven
Postcode5628 DB
CountryNetherlands
