KEEPOWER Keeppower 14500 - 840 mAh, 3,7 V Li-ionbatterij be Battery

High quality Sanyo cell (Made in Japan) with long life and high cycle stability. Protection / PCB with protection against short circuit, overload and deep discharge. Developed for the field of flashlights, LEDs, battery holders etc.

Keeppower 14500 PCB with lithium-ion battery protected

Please note the dimensions of the cell before buying! Due to the built-in electronics, the cell is not suitable for every application!
Height and diameter are larger than a standard 14500 cell without a PCB.

cell Sanyo UR14500P capacity 840mAh Min. Capacity 800mAh nominal voltage 3.7V charge voltage 4.2V ± 0.05V discharge voltage 2.75V Calculates internal resistance 0.19Ohm positive pole raised (button on top) Max. Discharge current 2C = 3A chemistry LiCo (ICR) Protection circuit PCB integrated 5A charging method CC-CV diameter 14.3 mm ± 0.15 mm height 52 mm ± 0.15 mm weight 20 g ± 1 g test results Lygte Info comparison test steam battery Safety note:

Please note that removing or damaging the protective electronics (PCB) may cause short circuit, fire or explosion.

Other features:

Lithium-ion batteries are thermally stable and have no memory effect.
They are lithium-based and characterized by a high energy density.

Technical data for "Keeppower 14500 - 840mAh, 3.7V Li-ion battery protected"

Normal charging current 800mAh / 3h Operating temperature charging 0°C - 45°C Operating temperature discharge -20°C - 60°C

Notes:

A special charger is required to charge lithium-ion batteries, which charge the batteries through a special charging process. (CCCV = constant current, constant voltage.) The batteries must not be charged above a voltage of 4.2 volts, otherwise there is a risk of fire and explosion. It is advantageous to charge batteries only to about 4.1 volts, as this significantly increases the life or number of charge cycles (possibly up to double). Only lithium-ion chargers should be used for charging. However, cheap chargers sometimes have the disadvantage that they do not safely switch off after the end of the charging process, but instead continue to charge the batteries with a small charging current, which can be dangerous.

In addition, rechargeable batteries and batteries do not belong in household waste! According to the law, dispose of them in the municipal collection points or in the designated [usually green] containers of the trade.
